Siklu Communication Ltd

EtherHaul™
Hundred Series
Products

v-icon

This suite of products is designed to be light weight and very small in size.  These two attributes are of critical import when designing radios that are targeting street level deployment.

v-icon

Starting with the EH-500/ EH-700 operating at up to 200Mbps and concluding with the EH-600/ EH-710 at speeds of 1Gbps, this family offers a range of capacities and corresponding distances supported.  All radios in this family are TDD based, and use Siklu’s patented OFDM Modem designed for mmWave at 60 – 70/80GHz.

v-icon

Operation in these bands offers large swaths of spectrum and coupled with extremely narrow radio beams provides virtually interference free operation today and tomorrow.

These features make the EtherHaul™
Hundred series ideal for street level applications such as wireless video security, Public WiFi Hot Spot backhaul and the emerging Intelligent Transportation System infrastructure.

Learn more about Etherhaul products

Carrier Class Construction and Performance

  • One of the smallest Gbps radios on the market delivering range and capacity, making site acquisition and installation on street furniture straightforward
  • Carrier grade predictable performance ideal for mission critical network connectivity
  • Up to 1Gbps throughput over ranges as far as 1.6 miles (2.6km)
  • Field proven advanced all-silicon integration yields a high 90-yr MTBF
  • Installation and support of Siklu radios can be performed by anyone, with minimal training
  • Optional integrated timing over packet 1588v2 and SyncE with SSM schemes facilitate reliable, accurate mobile backhaul synchronization
  • Prioritized payloads using hitless adaptive modulation synced with 8 levels of QoS.​

Want to learn more?

Spectrum Agility

  • Interference-free operation in the 60GHz band (EH-500 and EH-600) and the 70GHz band (EH-7X0)
  • Wide frequency support covering from 57GHz to 66GHz in a single product (EH-500/600)
  • The wide 60GHz band, pencil width beams and 11x non-overlapping, user-selectable channels yield the industry’s highest spectrum re-use factor (EH-500/600).
  • Over 5GHz of available spectrum in the 70GHz band, pencil width beams and 32 non-overlapping, user-selectable channels yield the industry’s highest scalability (EH-7X0).

Want to learn more?

Flexible Topology and Interfaces

  • Advanced networking toolkit to create flexible topologies in chains, drop & insert and sub-50msec resilient rings
  • Designed for easy installation and commissioning using embedded tools to optimize channel selection, load testing and zero-touch commissioning
  • A layer 2 product with a built in Ethernet switch, QoS and 3x1G Base-T ports
  • Dual PoE out for simplifying powering of cascaded radios, cameras and other devices

Want to learn more?

Siklu-EH-500TX-London
